Real Time Tracking,2G GPS Tracker — TR17
TR17 is a 2G vehicle positioning terminal supports real time tracking, historical playback, andhas multiple & advanced alarms included harsh breaking, sudden acceleration or sharpturning,overspeed alarms.Other customised alarms and features are available upon request.
In-Vehicle Positioning Core Chip
Supports multiple satellite signals, including BDS, GPS, Galileo, GLONASS, QZSS, and SBAS, and can concurrently process signals from three satellite constellations. It features interference detection and dynamic filtering, effectively resisting external signal interference and enabling rapid positioning even in complex environments like dense urban canyons. It also boasts an advanced low-power design, intelligent power management system, and a wide voltage range. With positioning accuracy of 2.5m CEP (1Hz), velocity accuracy of 0.1m/s CEP, and time accuracy of 25ns, it boasts a hot-start time-to-first-fix of 1s and a cold-start time-to-first-fix of 28s, meeting the needs of most in-vehicle positioning scenarios.
In-Vehicle GPS Tracker Alarm System
Equipped with five intelligent alarm systems: vibration alarm, power failure alarm, low battery alarm, overspeed alarm, and displacement alarm, it safeguards vehicle safety from multiple perspectives. From detecting anomalies to identifying anomalies to triggering alarms, every step is designed to minimize false alarms and eliminate true alarms, ultimately achieving a precise response to vehicle safety risks.
Wide Voltage Compatibility
With a wide voltage compatibility of 9-90V, the tracker is compatible with a wide range of vehicles on the market, eliminating the need for additional voltage module modifications and significantly reducing installation barriers and operating costs. Whether it’s personal vehicle safety monitoring, corporate fleet logistics and transportation management, or commercial vehicle tracking, this tracker’s wide voltage capability meets the needs of various vehicle scenarios.
Power and Fuel Cut Off Control
After connecting to the vehicle’s power and fuel systems through a wired design, users can remotely cut off the vehicle’s power and fuel supply via a management platform or SIM card commands, effectively preventing the risk of loss of control or theft. This wired design ensures a stable connection between the device and the vehicle’s power and fuel systems, eliminating signal delays or interruptions associated with wireless vehicle control. Combined with remote control, it’s suitable for both individual vehicle owners seeking to prevent vehicle theft and corporate fleets like logistics and rental companies seeking real-time vehicle management, providing more proactive and flexible vehicle safety management.
Technical Specifications
| Specification | TR17 |
|---|---|
| Network | GSM 850/900/1800/1900MHz |
| Working Voltage | DC 9V – 90V |
| Dimensions | 75mm * 33mm * 13mm |
| Location Accuracy | <10 Meters |
| Positioning Way | GPS + BDS + GLONASS + LBS |
| GNSS Chipset | HD8122 (88-channel) |
| Standby Battery | 55mAh |
| Working Temperature | -20°C to +75°C (-4°F to 167°F) |
| Storage Temperature | -25°C to +80°C (-13°F to 176°F) |
| Ingress Protection | IP65 |
| Weight | 40g |
| Warranty | 12+ Months |
Main Features
Real-Time Tracking
Geo-Fence
ACC Detection
IP65 Water-Resistant
DC 9-90V
TR17 Vehicle Tracking System GPS Tracker Applicable Scenarios
Car Anti-theft and Security Monitoring
Fleet Management
Logistics and Transportation
Bulk GPS Tracking Devices Ready-to-Ship
GREATWILL specializes in GPS tracker wholesale. We maintain a regular stock of market-proven devices to quickly fulfill orders for vehicle trackers, asset trackers, and heavy equipment monitors. We support OEM/ODM and customization services. Whether for your own business or for resale, the TR17 offers exceptional quality and value.
- Provide after-sales technical support and product testing
- Continuously adjust products to suit local conditions and vehicles
- Warranty period up to 3 years
- Sample delivery time is approximately 3-5 days.
- Large-volume orders take over 7 days.
- The device/platform software/SIM/IoT card undergo engineering inspection and testing before packaging and shipment.
- Multiple shipping methods supported.
- The multi-module positioning mode of GPS/BDS/GLONASS & LBS overcomes the limitations of single-satellite positioning and achieves highly accurate positioning in open areas. Even in areas with weak satellite signals, such as urban canyons and tunnels, LBS (base station positioning) can quickly compensate and ensure uninterrupted positioning. Whether commuting on urban roads or on freight routes in remote areas, the vehicle’s precise location can be accurately determined in real time, avoiding monitoring failures caused by positioning blind spots.
- In terms of alarm functions, in addition to maintaining the existing multi-dimensional safety protection, a low-battery alarm setting is now more tailored to actual usage needs. This feature is enabled by default and automatically transmits a low-battery alarm signal after 5 minutes when the device is disconnected from the external power supply. This design not only prevents false alarms caused by a temporary loose external power supply, but also promptly reminds the user to switch to internal battery power, urging the user to check the power supply as soon as possible (such as reconnecting the external power supply or charging the device) to prevent positioning and alarm interruptions due to battery depletion. It is particularly suitable for trucks and official vehicles that rely on external power for a long time.
- The real-time positioning function, as a core feature, allows users to configure the positioning frequency (e.g., 10 seconds or 1 minute) based on their needs. Vehicle location and driving trajectory are updated in real time via the management platform or mobile app. Whether individual drivers are checking vehicle status or corporate fleets are monitoring transport progress, both provide dynamic visualization and full control.
- The SOS alarm provides a rapid response channel for emergencies. When drivers encounter an emergency (such as a traffic accident or hijacking), they can trigger an alarm with a single click using the SOS button on the tracker. The device immediately sends location information and an alert to pre-set emergency contacts, facilitating rapid rescue and providing an additional layer of safety for drivers and passengers.
